Applied Systems Engineering ASE2000 User Manual

ASE2000 V2 Communication Test Set User Manual 192
Quality shows quality codes applicable to this ASDU type
Mask, if 1, instructs the ASE2000 to toggle the value of this object each time it is sent. If 0, the
value is not toggled
Double Point
Double and single point information is the same except that the single point’s SPI eld is replaced
with DPI for a double point.
Step Position
VTI is the object value
Quality shows quality codes applicable to this ASDU type
Transient State is an additional ag to indicate transient or non-transient status
Bitstring
BSI is the object value
Quality shows quality codes applicable to this ASDU type
Measured Values
NVA is the name of the object value used for Normalized objects. SVA is used for scaled objects
and FVA for oating point object
