ASE2000 V2 Communication Test Set User Manual 84
13.2.1. RTU/IED Simulation Mode – RS-232
ASE2000 Test Set
BCOM-USB
RS-232 Cable
USB Cable
Master
Station
RS-232 Cable
Null Modem
Adapter
13.2.2. Monitor Mode – RS-232
Master
Station
RS-233
Modem Cable
Master Station
Modem
RTU
RTU
Modem
RS-232
Monitor Cable
Communication
Line
ASE2000 Test Set
BCOM-USB
RS-232 Cable
USB Cable
