ASE2000 V2 Communication Test Set User Manual 213
30
30. Telegyr8979–ProtocolSpecic
Most test set operations are independent of the specic protocol being used and are described
in the non-protocol specic topics. The most common protocol specic activity is dening the
message structure for a particular RTU. This involves dening the number and types of points
(analog, digital, and accumulator) congured in the device (RTU, IED) under test. This information
enables the test set to issue the proper data scan request and to parse and correctly display
information in data response messages. The following sections will describe the protocol specic
considerations, if any, for Task and Exchange operational modes and, within those modes, any
communication mode (Line Monitor, Master Simulation, and RTU Simulation) protocol specic
considerations.
30.1. Telegyr 8979 – Exchange Mode
For Exchange Mode, protocol specic tasks are editing Exchange Denition and setting RTU
address information.
30.1.1. Telegyr8979–EditExchangeDenition
Congure one or more Read exchanges (Analog Force Report, Analog Group Force Report,
Indication Force Report) with device point information. The specic Read exchange(s) to
congure is a function of how points are congured in the device. In the following example, the
device conguration consists of 16 Indication and 8 Analog points.
From the Exchange view, right-click on the line containing the Analog Force Report exchange
and select Edit Exchange Denition.
Under the “To Master” section, expand the element “Analog: unknown quantity of blocks”, set
“Repeat Count” to 8 (1 analog point per block), then OK.
