ASE2000 V2 Communication Test Set User Manual 95
CDL Carrier Detect Sensitivity - Factory setting is completely clockwise. Sensitivity
is –30 dBm in the cw direction to –48 in the ccw direction.
16.2. Adjusting Modems with Orange or Yellow Colored
Potentiometers
TXL Transmitter Gain - Factory setting is 1/8 of a turn from the clockwise (cw)
end. Transmit levels range from –50 dBm in the cw direction to –6 dBm in the
counter-clockwise (ccw) direction.
RXL Receiver Gain - Factory setting is ¼ of a turn from the clockwise end. Receive
sensitivity levels range from –6 dBm in the cw direction to –54 dBm in the ccw
direction.
CDL Carrier Detect Sensitivity - Factory setting is completely clockwise. Sensitivity
is –30 dBm in the cw direction to –48 in the ccw direction.
