18. ASE2000 Kit Contents
The ASE2000 is provided in kit form with all the necessary software, cables, adaptors, and
documentation to congure an operational test set. The actual kit contents will vary according to
ASE2000 model and are detailed in the following sections.
18.1. Model ASE2000-USB-M
• ASE2000 Software Installation CD-ROM. This CD contains both the ASE2000 Application
software installation les and the I/O driver les for the ASE dual-channel BCOM-USB device
and the SafeNet Pro/SuperPro Security Plug (dongle).
• ASE dual channel BCOM-USB device
• USB Cable – PC to BCOM-USB
• USB to ASE 2-Channel Modem Power Cable
• Two RS-233 Cables, each with a DB-9 Female connector on one end and a DB-25 Male
connector on the other end.
• ASE Bell-202 or CCITT V.23 dual-channel modem and two RJ-11 cables with fork-lug
connectors (optional only with the BCOM-USB models)
• DB-25 female-female gender changer
• DB-25 null modem adapter
• DB-9 to DB-25 adaptors
• RS-232 monitor-mode adapter cable
• ASE2000 documentation - ASE2000 Communication Test Set User Guide.
18.2. Model ASE2000-USB-RS
• ASE2000 Software Installation CD-ROM. This CD contains both the ASE2000 Application
software installation les and the I/O driver les for the ASE dual-channel BCOM-USB device
and the SafeNet Pro/SuperPro Security Plug (dongle).
• ASE dual channel BCOM-USB device
• USB Cable – PC to BCOM-USB
• Two RS-233 Cables, each with a DB-9 Female connector on one end and a DB-25 Male
connector on the other end.
• DB-25 female-female gender changer
• DB-25 null modem adapter
• DB-9 to DB-25 adaptors
• RS-232 monitor-mode adapter cable
• ASE2000 documentation - ASE2000 Communication Test Set User Guide.
18.3. Model ASE2000-COM
• ASE2000 Software Installation CD-ROM. This CD contains both the ASE2000 Application
software installation les and the I/O driver les for the ASE dual-channel BCOM-USB I/O card
and the SafeNet Pro/SuperPro Security Plug (dongle).
• SafeNet parallel port (LPT) or USB dongle for desktop or laptop PCs. The hardware dongle
included in this package enables the ASE2000 software.
• Two RS-233 Cables, each with a DB-9 Female connector on one end and a DB-25 Male
connector on the other end.
