27. Flywheel connector
28. Regulator connector
29. Regulator connector on the vehicle cable harness
TABLE I
Right side
30. Instrument panel branch vehicle cable harness
31. Fan connector
32. Clamp
TABLE J
32A. Tie
32B. Fan connector
32C. Instrument panel branch vehicle cable har-
ness
TABLE J1 - EXHAUST VALVE ACTUATOR
Positioning and calibration
Electrical system RSV4 Factory a-PRC
ELE SYS - 116
