LATERAL UNDERFAIRINGS
•
The following procedure is relative to a
single lateral underfairing, but is appli-
cable to both, except where specified
otherwise.
•
Unscrew and remove the central un-
derfairing fixing screw.
•
Remove the respective side fairing.
•
Unscrew and remove the lower screw.
•
When working on the left hand side of
the vehicle, remove the underfairing
taking particular care not to damage
the fittings with the central underfair-
ing.
•
When working on the left hand side of
the vehicle, support the left hand un-
derfairing, unscrew and remove the
two nuts, retrieve the screws and lower
the regulator.
•
Remove the underfairing.
Bodywork RSV4 Factory a-PRC
BODYW - 500
