Air box
FILTER BOX COVER REMOVAL
•
Remove the control unit.
•
Disconnect the air temperature sensor
connector.
•
Move the two rear coil connectors
See also
Control unit
•
Unscrew and remove the four upper
injector screws.
•
Move the upper injector mounting.
•
Disconnect the variable geometry in-
take system connector.
RSV4 Factory a-PRC Bodywork
BODYW - 501
