Disconnect the fuel pump connector.
•
Remove the tank.
Front mudguard
•
Working from both sides, unscrew and
remove the two screws.
•
Remove the front mudguard.
Instrument cluster support
REMOVAL
•
Remove the instrument panel.
•
Working on both sides, unscrew and
remove the two screws fastening the
arch brace to the headstock.
•
Retrieve the cable grommet.
•
Unscrew and remove the five semi-
arch brace fixing screws.
See also
Bodywork RSV4 Factory a-PRC
BODYW - 506
