Insert the countershaft from the alter-
nator side.
•
Turn the countershaft until aligning the
key seat on the countershaft and on the
gear.
•
Insert the drive key.
•
Place the washer.
•
Turn the nut on the countershaft.
•
Block crankshaft rotation using the
specific tool.
•
Tighten the nut on the countershaft.
Specific tooling
020849Y Clutch retainer
Main transmission gear removal
•
Remove the clutch.
•
Turn the crankshaft and align the ref-
erences on the countershaft gear and
the primary shaft gear.
•
Block crankshaft rotation using the
specific tool.
Specific tooling
020850Y Primary gear lock
RSV4 Factory a-PRC Engine
ENG - 353
