alternator;
•
water pump;
•
gearbox unit;
•
primary drive shaft gear
•
both timing chains;
•
the chain sliders;
•
oil sump;
•
the gear selector pin spacer;
•
starter motor and intermediate gear;
•
countershaft.
See also
Magneto flywheel removal
Water pump
Disassembling the gearbox
Main
transmission gear removal
Front head removal
Rear head removal
Removing the
oil sump
Balancing
countershaft removal
Crankcase opening
•
Position the engine with the heads fac-
ing upward, unscrew and remove the
screw (24).
Engine RSV4 Factory a-PRC
ENG - 356
