Instrument panel
•
Remove the windshield.
•
Unscrew and remove the two screws.
•
Remove the instrument panel mount-
ing cover.
•
Move the instrument panel, removing
the rubber rings from the seats on the
support.
•
Rotate the instrument panel connector
retainer lever.
•
Remove the connector.
•
Remove the instrument panel.
NOTE
WHEN REFITTING THE CONNECTORS, THE SLIDES MUST MOVE FREELY TO THE END OF
STROKE, WHICH HELPS WITH THE INSERTION OF THE CONNECTOR: YOU MUST HEAR THE
RELEASE OF THE RETAINING TANG AT THE END OF STROKE.
RSV4 Factory a-PRC Bodywork
BODYW - 493
