Remove the spring guide (3), noting its
direction of installation to ensure cor-
rect reassembly.
•
Remove the other spring guide snap
ring (4).
•
Remove the ring (5) and extract the
rubber buffer (6)
•
Remove the ring nut, on which the
threaded pipe is attached, from the
pumping member pin.
•
Remove the rubber O ring.
•
Remove the guide bushing and the
counterspring.
Checking the components
Stem
Check the sliding surface for scorings and/or scratches.
These scorings can be eliminated by rubbing them with wet sandpaper (grain 1).
Suspensions RSV4 Factory a-PRC
SUSP - 410
