Use a plain slot screwdriver to remove
the oil seal (5).
CAUTION
PLACE A STRIP OF RUBBER ON THE EDGE OF THE
SLEEVE TO PROTECT IT FROM DAMAGE WHEN REMOV-
ING THE OIL SEAL (5).
Replace the following components with new ones:
- oil seal (5)
- dust gaiter (3)
CAUTION
BE EXTREMELY CAREFUL IN ORDER THAT NO FOREIGN BODIES GET INTO THE SLEEVE OR
THE WHEEL HOLDER STEM. NEVER REUSE OIL
•
Use the Öhlins tool to unscrew the
pumping member pin fixing ring nut.
•
Remove the pumping member pin unit.
•
Remove the spring guide snap ring (1)
•
Remove the spring guide support ring
(2)
RSV4 Factory a-PRC Suspensions
SUSP - 409
