Specification Desc./Quantity
Steering rake 26.5° (measurements with reference to bare frame). For the
Factory versions the adjustments allow for variations of "+" or
"-" 1°
Trail 110 mm (4.33 in)
(with adjustable inserts, headstock as a standard feature)
SUSPENSION
Specification Desc./Quantity
Front fork Öhlins upside down units with adjustable hydraulic damping
and 43 mm (1.69 in) diam. stanchions with Tin surface coating)
Front wheel travel 120 mm (4.72 in)
Rear shock absorber Lateral, with progressive linkage and APS system. ÖHLINS
piggy-back shock absorber with adjustable spring preloading,
wheelbase and hydraulic compression and rebound damping.
Rear wheel travel 130 mm (5.12 in)
SIZES A AND B
Specification Desc./Quantity
Size "A" 639.5 mm (25.18 in) (measurements refer to the bare chassis)
Size "B" 329.5 mm (12.97 in) (measurements refer to the bare chassis)
Brakes
BRAKES
Specification
Desc./Quantity
Front Dual 320 mm (12.59 inches) diam. floating disc, single block
calipers with radial fixing and four pistons 34 mm diam. (1.34
inches) and 2 pads - radial pump and brake pipe in metal braid.
Rear disc type -220 mm diam. (8.66 inches), 2-piston callipers - 32
mm diam. (1.25 inches) - pump with built-in tank and metal
braid pipe.
Wheels and tyres
WHEEL RIMS
Specification
Desc./Quantity
Front wheel rim 3.50 x 17" Forged
Rear wheel rim 6.00 x 17" Forged
TYRES
Specification
Desc./Quantity
Tyre model Pirelli DIABLO Super Corsa SP
Metzeler RACETEC K3
Michelin Power One
Characteristics RSV4 Factory a-PRC
CHAR - 14
