APRILIA RSV4 Factory a-PRC 2009 User Manual

COOLING
pos.
Description Type Quantity Torque Notes
1 Flanged TE screws for fastening the
water radiator mounting bracket to
frame
M6x20 2 10 Nm (7.37 lbf ft) -
2 Self-tapping screw for fastening the
water radiator to the mounting brack-
et
- 1 2 Nm (1.47 lbf ft) -
3 Screw fastening pipe grommet for
By-pass water hose
M5 1 6 Nm (4.42 lbf ft) -
4 Screws fastening electric fan to wa-
ter radiator
M4 6 2 Nm (1.47 lbf ft) -
5 Flanged TE screw for fastening the
water radiator to the mounting brack-
et
M6x20 1 7 Nm (5.16 lbf ft) -
Characteristics RSV4 Factory a-PRC
CHAR - 24
