Pos. Descrizione Tipo Quantità Coppia Note
2 Viti TE fl. per fissaggio staffa a telaio M6x20 2 10 Nm (7.38 lbf ft) -
Removing
•
Drain the engine oil.
•
Remove both fairings and the radiator
cowl.
•
Release the clamp and disconnect the
right hand radiator pipe.
•
Release the clamp and disconnect the
left hand radiator pipe.
See also
Replacement
•
Remove the split pin.
•
From the opposite site, remove the
coolant radiator-oil radiator connector
pin.
Chassis RSV4 Factory a-PRC
CHAS - 458
