HANDLE PAINTED AND PLASTIC COMPONENTS WITH CARE; BE CAREFUL NOT TO SCRATCH
OR DAMAGE THEM.
LOWER SIDE FAIRINGS
•
The operations described below are
valid for both lower side fairings.
•
Remove the side fairing.
•
Unscrew and remove the screw and
remove the lower side fairing.
Fairing mounting panels
CENTRAL UNDERFAIRING
•
Remove the three windshield fixing in-
serts.
•
Unscrew and remove the two screws.
•
Ease off the central underfairing, tak-
ing care not to damage the fittings with
the lateral underfairings and the wind-
shield.
•
Working from both sides, unscrew and
remove the lower screw.
RSV4 Factory a-PRC Bodywork
BODYW - 499
