Disconnect the two exhaust butterfly
valve control cables
•
Unscrew and remove the two valve ac-
tuator motor screws
•
Remove the valve actuator motor to-
gether with the heat shield.
Engine oil cooler
RADIATORE OLIO
Pos.
Descrizione Tipo Quantità Coppia Note
1 Screws fastening oil radiator to
mounting bracket
M6 1 7 Nm (5.16 lbf ft) -
RSV4 Factory a-PRC Chassis
CHAS - 457
