Holding up the pin, insert the preload
spring.
•
Fit the lock nut for the preload spring
(1).
•
Fit the nut (2).
•
Keeping the spring compressed, tight-
en the nut completely.
•
Screw the complete cap onto the
pumping member pin.
•
Tighten the cap using a wrench to
block the lower spring ring nut.
•
Tighten the upper adjustment cap to
bring it into contact with the lower nut
on the cap.
•
Use the specific Öhlins tool to tighten the upper cap on the sleeve to 20 Nm (14.75 lbf ft).
Steering damper
Suspensions RSV4 Factory a-PRC
SUSP - 416
