Remove the flywheel cover.
•
Remove the Seeger ring.
•
Remove the shim washer.
•
Remove the oil seal.
CAUTION
DURING REFITTING REPLACE THE OIL SEAL WITH A
NEW ONE OF THE SAME TYPE.
SET THE NEW OIL SEAL WITH THE MARKING ON THE
EDGE FACING OUTWARD.
See also
Removing the flywheel cover
Installing the flywheel
•
Position the flywheel on the crankshaft.
•
Block flywheel rotation using the spe-
cific tool.
•
Tighten the screw.
Specific tooling
020848Y Flywheel retainer (Mitsubishi)
020914Y Flywheel retainer
Engine RSV4 Factory a-PRC
ENG - 288
