Connector location (if available):
Under the right dynamic air intake.
Pin-out:
•
PIN 1 - Power negative/Signal nega-
tive (white)
•
PIN 2 - Power positive/Signal positive
(white/brown)
DIAGNOSIS INSTRUMENT
Parameters:
Speed (km/h) - Front wheel speed
DIAGNOSIS INSTRUMENT: ELECTRICAL ERRORS
C1002 Front speed sensor: short circuit.
It activates when the two wires are shorted one with the other or if the negative wire is shorted to positive
(e.g. 12V)
Troubleshooting:
Check insulation of white cable and white/brown cable: if NOT OK, restore cable harness; if OK, check
positive insulation (12V) of the white cable. If NOT OK, restore; if OK, check with sensor disconnected
and key ON that power voltage is slightly below battery voltage. If OK, change the sensor; if NOT OK,
change the CLF control unit
C1003 Front speed sensor: electric malfunction.
Missing sensor or interrupted wire or short circuit to negative of one of the two wires.
Troubleshooting:
Check the sensor connector and the CLF control unit connector. If it is not OK, restore the connectors;
if it is OK, check continuity of the white/brown cable across wiring-side sensor PIN 2 and PIN 3. If NOT
OK, restore cable harness; if OK, check the continuity of the white cable across wiring-side sensor PIN
1 and CLF control unit connector PIN 6. If NOT OK, restore cable harness; if OK, check the white/brown
cable ground insulation. If NOT OK restore cable harness; if OK, check the white cable ground insula-
tion. If NOT OK restore cable harness; if OK, check with sensor disconnected and key ON that power
voltage is slightly below battery voltage. If OK, replace the sensor; if NOT OK, replace the CLF control
unit
C1008 Front speed sensor: electric malfunction.
It activates when the positive wire is shorted to ground.
Troubleshooting:
Check continuity of white/brown cable across wiring-side sensor PIN 2 and CLF connector PIN 3: if
NOT OK, restore cable harness; if OK, check ground insulation of the white/brown cable. If NOT OK,
restore cable harness; if OK, check with sensor disconnected and key ON that power voltage is slightly
below battery voltage. If OK, replace the sensor; if NOT OK, replace the CLF control unit.
Electrical system RSV4 Factory a-PRC
ELE SYS - 162
