connector: between head cover and fil-
ter box on left side (3-ways white con-
nector).
Electrical specifications:
PIN 64: gear indication: closed circuit (continuity);
gear engaged: open circuit (infinite resistance).
Gear engaged circuit resistance: 1st gear: 0.8
kohm, 2nd gear 0.5 kohm, 3rd gear 15.0 kohm, 4th
gear 6.9 kohm, 5th gear 2.8 kohm, 6th gear 1.5
kohm.
Pin out:
White/Black: ground from ECU, Light Blue: + 12V
from ECU (gear), Pink: + 5V from ECU (gears).
CAUTION
BEFORE CARRYING OUT ANY TROUBLESHOOTING,
CAREFULLY READ THE GENERAL TROUBLESHOOTING
CONCEPTS FOR ELECTRICAL DEVICES AT THE BEGIN-
NING OF THE CHECK AND CONTROL SECTION IN THE
ELECTRICAL SYSTEM CHAPTER.
DIAGNOSTICS INSTRUMENT: STATUSES
Gearbox in neutral
•
Yes/No
Gear engaged: 0 - 1 - 2- 3 - 4 - 5 - 6
DIAGNOSTICS INSTRUMENT: ELECTRICAL ERRORS
Gear sensor P0461
•
shorted to positive or open circuit / shorted to negative.
Error cause
•
If the circuit is open, shorted to positive: excessive voltage has been detected at PIN 72. If
shorted to negative: voltage equal to zero has been detected at PIN 72.
Troubleshooting
•
If the circuit is open, shorted to positive: the error is detected with gear engaged only. Check
the sensor connector and the VEHICLE connector of the control unit: if not OK, restore; if
they are OK, check the continuity of the Grey/Black cable between the two connectors: if
not OK, restore; if they are OK, with key set to ON and control unit connector disconnected,
check from the control unit side if the cable is in voltage: if it is in voltage, disconnect the
sensor connector and check if the cable is in voltage: if it is in voltage, restore the cable
harness; if it is not in voltage, replace the sensor (there is an interruption or shorted to positive
of the Pink/Black cable in the section from the sensor connector to the sensor or inside the
sensor).
RSV4 Factory a-PRC Electrical system
ELE SYS - 215
