APRILIA RSV4 Factory a-PRC 2009 User Manual

INSTRUMENT PANEL
pos. Description Type Quantity Torque Notes
1 Screws fastening the rubber rings to
the instrument panel
SWP 4.9 3 3 Nm (2.21 lbf ft) -
2 Instrument panel mounting shell fix-
ing screws
SWP 4.9 5 2 Nm (1.47 lbf ft) -
3 Screws fastening instrument panel
mounting to chassis
M6 4 8 Nm (5.9 lbf ft) -
WINDSHIELD
pos.
Description Type Quantity Torque Notes
1 Windshield fixing screws M4 4 0.5 Nm (0.37 lbf ft) -
2 Rear-view mirror fixing nuts M6 2 + 2 10 Nm (7.37 lbf ft) -
3 - Screws fastening the side fairings
to front fairing
M5 4 1 Nm (0.74 lbf ft) -
Characteristics RSV4 Factory a-PRC
CHAR - 22
