unit connector, b) inertia sensor platform (Sensor box) connector and check the continuity
across inertia sensor platform (Sensor box) pin 3 and CLF control unit pin 9. If NOT OK,
change the vehicle cable harness; if OK, check the continuity across inertia sensor platform
(Sensor box) pin 2 and CLF control unit pin 8. If NOT OK, change the cable harness; if OK,
check for the correct power supply (12V) at pin 4 and ground at pin 1 of the CLF control unit.
If NOT OK, restore the cable harness; if OK, change the inertia sensor platform (sensor box).
•
Configuration error - Open the Navigator devices status page to check if the control unit
setting is actually consistent with the motorcycle setting. Example: if the bike is equipped
with inertia sensor platform (Sensor box), the correct status we should find on the Navigator
devices status page will be: Aprilia Traction Control Performance (in a bend) PRESENT.
While on a bike equipped with inertia sensor platform (Sensor box) and Navigator indication:
Aprilia Traction Control Performance (in a bend) NOT PRESENT update the control unit.
Rear wheel radius acquisition P0510
•
CAN error during acquisition/Invalid value.
Error cause
•
In case of CAN error during acquisition, system warns that the procedure can not be com-
pleted due to a communication problem on the CAN line. In case of invalid value, it means
that on key-ON an error of transcription occurred - from the non-volatile memory (EEPROM)
to the volatile one (RAM) - of the value concerning the rear wheel radius. In this case the
default value is used.
Electrical system RSV4 Factory a-PRC
ELE SYS - 248
