REAR BRAKE PUMP
pos. Description Type Quantity Torque Notes
1 Rear brake rod lock nut M6 1 12 Nm (8.85 lbf ft) -
2 Rear brake pump fixing screws M6 2 8 Nm (5.9 lbf ft) -
3 Rear brake lever fixing screw M8 1 25 Nm (18.44 lbf ft) -
REAR BRAKE CALLIPER
pos.
Description Type Quantity Torque Notes
1 Rear brake disc fixing screws M8 5 30 Nm (22.13 lbf ft) Loct. 243
2 Odometer sensor fixing screw M6 1 10 Nm (7.38 lb ft) -
3 Rear brake calliper mounting plate
lock pin
M12 1 50 Nm (36.88 lbf ft) Loct. 243
4 Rear calliper fixing screw M5 2 25 Nm (18.44 lbf ft) -
5 Brake pipe clamp fixing screw M5 2 4 Nm (2.95 lbf ft) -
- Brake pipe bracket fixing screw M5 2 4 Nm (2.95 lbf ft) -
RSV4 Factory a-PRC Characteristics
CHAR - 35
