APRILIA RSV4 Factory a-PRC 2009 User Manual

The procedure then continues with screws 1 and
4
If necessary, operate on the Master screws (1-4)
as follows:
•
Remove the filter casing cover.
•
Remove the four fixing screws of the
cones with variable height (1) (IF FIT-
TED).
•
Remove the remaining cones by un-
screwing the eight screws (2).
•
Remove the two caps (3).
CAUTION
WHEN REFITTING THE COVERS PAY ATTENTION TO NOT
DAMAGE THEM.
To ensure correct engine operation, one of the two screws of each throttle body must always be closed.
Motorcycles are factory set with screws 1 and 2 turned by half a turn and screws 3 and 4 closed.
RSV4 Factory a-PRC Power supply
P SUPP - 397
