APRILIA RSV4 Factory a-PRC 2009 User Manual

Handlebar
HANDLEBAR AND CONTROLS
pos.
Description Type Quantity Torque Notes
1 Screw fastening the semi-handlebar
collar to the fork sleeves
M8 1 + 1 25 Nm (18.44 lbf ft) -
2 Semi-handlebar safety screw M6 1+1 10 Nm (7.37 lbf ft) -
3 Anti-vibration counterweight fastener M18x1.5 1+1 20 Nm (14.75 lbf ft) -
4 Right light switch M4 2 1.5 Nm (1.11 lbf ft) -
5 Left light switch M5 2 1.5 Nm (1.11 lbf ft) -
6 Throttle control fixing screws M5 2 2 Nm (1.47 lbf ft) -
7 Traction control control unit fixing
screw
M4 1 2 Nm (1.47 lbf ft) -
Suspensions RSV4 Factory a-PRC
SUSP - 402
