ALWAYS REPLACE BOTH GASKETS.
ALWAYS REPLACE THE GASKETS WITH OTHERS OF THE SAME TYPE.
REAR WHEEL AXLE
•
Use a dial gauge to check the wheel
axle eccentricity (1). Replace the
wheel axle if the eccentricity exceeds
the limit value (1).
Characteristic
Maximum eccentricity:
0.25 mm (0.0098 in)
REAR WHEEL RIM
•
Using a dial gauge, check that the ra-
dial (A) and the axial eccentricity (B) of
the rim (2) do not exceed the limit val-
ue.
An excessive eccentricity is usually caused by
worn or damaged bearings. Replace the rim (2) if
after replacing the bearings, the value is not within
the specified limit.
Characteristic
Maximum radial and axial eccentricity:
0.8 mm (0.031 in)
RSV4 Factory a-PRC Suspensions
SUSP - 427
