Unscrew and remove the nut and re-
trieve the washer.
•
Working from the right side, loosen and
remove the locking ring nut.
•
Turn the swingarm pin (2) anticlock-
wise, which turns and loosens the ad-
justment bushing (3) completely.
REMOVAL SHOULD BE CARRIED OUT WITH UTMOST
CAUTION.
SUPPORT THE SWINGARM FROM THE FRONT TO AVOID
ACCIDENTAL FALLS.
PLACE A WOODEN SUPPORT UNDER THE FRONT PART
OF THE REAR SWINGARM TO PREVENT IT FROM LOW-
ERING AND TO KEEP IT UPRIGHT.
Chassis RSV4 Factory a-PRC
CHAS - 440
