Moving the bracket outwards, it is then
possible to remove it by sliding it out.
CAUTION
DURING THE REFIT PHASE, MAKE SURE THAT THE MAIN CABLE HARNESS IS CORRECTLY
POSITIONED ON THE CAVITY OF THE RADIATOR RETAINER BRACKET, IN ORDER TO PRE-
VENT THE CABLE HARNESS FROM COMING INTO CONTACT WITH THE RADIATOR AT HIGH
TEMPERATURE AND DAMAGING ITSELF.
RADIATOR REMOVAL
•
Drain off the cooling system.
•
Remove the front underfairings and the
hand grip position sensor
•
Disconnect both cooling fan connec-
tors.
•
Disconnect the expansion tank breath-
er pipe from the pipe grommet.
See also
Coolant replacement
Fairing mounting panels
Twistgrip position sensor
Cooling system RSV4 Factory a-PRC
COOL SYS - 480
