APRILIA RSV4 Factory a-PRC 2009 User Manual

LUBRICATION
pos. Description Type Quantity Torque Notes
1 Oil filter union fixing screw - 1 30 Nm (22.13 lbf ft) -
2 Oil drainage plug - 1 30 Nm (22.12 lbf ft) -
3 Oil sump fixing screws M6x30 7 12 Nm (8.85 lbf ft) -
4 Oil sump fixing screws M6x22 4 12 Nm (8.85 lbf ft) -
5 Oil sump fixing screws M6x25 1 12 Nm (8.85 lbf ft) -
6 Screws fastening the pump to the
crankcase
M6 5+1 10 Nm (7.37 lbf ft) -
7 Oil pipe union fixing screw M6 1 8 Nm (5.90 lbf ft) Loct. 243
- Screw fastening the diffuser in the oil
sump
- 1 10 Nm (7.37 lbf ft) -
SECONDARY AIR SYSTEM
pos.
Description Type Quantity Torque Notes
1 Secondary air system solenoid
screws
- 2 10 Nm (7.37 lbf ft) -
Characteristics RSV4 Factory a-PRC
CHAR - 50
