APRILIA RSV4 Factory a-PRC 2009 User Manual

FRONT ELECTRICAL SYSTEM
pos.
Description Type Quantity Torque Notes
1 Fall sensor mounting fixing screw M6 1 8 Nm (5.9 lbf ft) -
2 Horn fixing screw M8 1 15 Nm (11.06 lbf ft) -
3 Screw fastening the voltage regula-
tor to the inner fairing
M6 2 6 Nm (4.42 lbf ft) -
4 Shear head screw (to the left of the
ignition lock)
M8 1 Manual Tighten until the
head shears off
5 Right hand ignition lock screw M8 1 20 Nm (14.75 lbf ft) -
Electrical system RSV4 Factory a-PRC
ELE SYS - 96
