ASCOM d83 - Operation

Maintenance
USER MANUAL
Ascom d83 DECT Handset
Orange, flashing (100 ms on, 800 ms off) Change phone indication during Easy Replacement.
Red, flashing (100 ms on, 800 ms off) Error indication during Easy Replacement. Put back
new portable in charger.
Red, flashing (900 ms on, 100 ms off) Error during Easy Replacement. Service needed for
both portables.
15.3 Attach the Hinge-type Clip
Attach the hinge-type belt clip as described in the illustration below.
Figure 18. Attach the hinge-type clip into position
15.4 Attach the Swivel-type Clip
Attach the swivel-type belt clip as described in the illustration below.
Figure 19. Attach the swivel-type clip into position
92 TD 93434EN / 01 December 2021 / Ver. B
