16 DG14 and DG16 Board & Sensor Reference Manual
Table 1.7 lists the options in the order in which they appear in the RIO response:
The altitude limits removed [A} option and the velocity limits removed [V] option require an export
license.
Table 1.7. DG16 Option Descriptions
Option Description
[W = 20 Hz]
[T = 10 Hz]
[5 = 5 Hz]
[2 = 2 Hz]
[1 = 1 Hz]
Position update rate
[W = 20 Hz]
[T = 10 Hz]
[5 = 5 Hz]
[2 = 2 Hz]
[1 = 1 Hz]
Raw measurement update rate
[O] Raw Data Output
[P] Carrier Phase Tracking
[U] Differential RTCM - Remote Station
[B] Differential RTCM - Base Station
[K] RTCM Type 18/19 message generation (available
only with RTCM Base option)
[L] Timing Pulse Output (1PPS)
[E] Photogrammetry Event Marker
[C] Strobe Correlator
[N] Beacon
[Y] SBAS
[X] User defined messaging
[D] Multi-base differential
[R] Third serial port (C)
[A] Altitude limit removed
[V] Speed limit removed
