272
2467S–AVR–07/09
ATmega128
Boundary-scan
Descriptio
n
Language Files
Boundary-scan Description Language
(BSDL) files describe Boundary-scan capable devices in
a standard form
at used by automated
test-gener
ation software. The or
der and function of
bits in
the Boundary-scan Data
Register are included in this descri
ption.
