USE AND MAINTENANCE MANUAL
ATTILA
77
EN
AL - Alarms
PARAMETER DESCRIPTION UM R290
R455a/
R452a
Min Max
HAL Upper limit for alarm all probes [°C] °C 80 80 -100 200
BAL Lower limit for alarm all probes [°C] °C -52 -52 -100 200
PAO Alarm activation delay at switch-on [Minutes] min 1 1 0 150
CnF - General configuration
PARAMETER DESCRIPTION UM R290
R455a/
R452a
Min Max
dEA ModBus communication serial address 1 1 0 14
LdL Minimum displayable value [°C] °C -55 -55 -55 400
HdL Maximum displayable value [°C] °C 100 100 -55 400
dro Display in °C (0) or °F (1) 0 0 0 1
PSd
Programme start waiting time from selection
[seconds]
sec 10 10 0 60
STl Machine time count in stop [min] min 20 20 0 100
H01 Display Language ( 0 - Ita, 1 - Eng, 2 - Fra) 0 0 0 15
H02 Display Format (0 - Easy, 1 - Advanced) 0 0 0 1
DN Number of displays 1 1 1 2
H11 Digital input function ( 0 - Disabled, 3 - Door open ) 3 3 0 3
H21
Relay function 1 ( 0 - None, 1 - Compressor, 2 -
Wait compressor start, 3 - Evaporator, 4 - Condenser,
5 - AUX, 6 - Alarm)
1 1 0
MAX
RELAY
- 1
H22
Relay function 2 ( 0 - None, 1 - Compressor, 2 -
Compressor start, 3 - Evaporator, 4 - Condenser,
5 - AUX, 6 - Alarm)
3 3 0
MAX
RELAY
- 1
H23
Relay function 3 ( 0 - None, 1 - Compressor, 2 -
Wait compressor start, 3 - Evaporator, 4 - Condenser,
5 - AUX, 6 - Alarm)
4 4 0
MAX
RELAY
- 1
H24
Relay function 4 ( 0 - None, 1 - Compressor, 2 -
Compressor start, 3 - Evaporator, 4 - Condenser,
5 - AUX, 6 - Alarm)
5 5 0
MAX
RELAY
- 1
CP Core probe presence 1 1 0 1
KPWD Parameters setting password 111 111 0 999
