86
1. Diagnostics Toolbar Buttons – see Table 4-2 Top Toolbar Buttons on Service Menu
for details.
2. Main Section
⚫ Name Display Area — displays the names and current values of the parameter
items.
a) Settings Icon — tap the settings icon at the right side of the parameter name
to select a data display mode and set the value range.
b) Information Icon — tap the information icon at the right side of the
parameter name to view more information.
⚫ Display Mode
There are three types of display modes available for data viewing. Select the
proper mode for diagnostic purpose.
Tapping the Settings icon on the right side of the parameter name to access
the details of data stream page. There are three buttons to configure the data
display mode, and a Restore Default Settings button to return to default
settings.
Each parameter item displays the selected mode independently.
Analog Gauge Mode — displays the parameters in the form of an analog meter
graph.
Text Mode — this is the default mode that displays the parameters in texts,
displaying in a list format.
NOTE
Status parameters, such as a switch reading, can primarily be viewed in test form such
as ON, OFF, ACTIVE, and ABORT. Whereas, value parameters, such as a sensor
reading, can be displayed in text mode and additional graph modes.
Waveform Graph Mode — displays the parameters in waveform graphs.
3. Function Buttons
The operations of available function buttons on Live Data screen are described
below:
Create PDF — creates a printable live data PDF file.
ESC — returns to the Function Menu.
