Icon Description
Presence icon indicating this contact's phone is busy with the
Send All Calls feature active. See Presence icons topic for more
information. This icon also designates that a feature is not
available at this point of a call.
Indicates that the deskphone is not connected to the session
manager and is operating in "failover" mode. Some features may
not be available or work correctly. Icon also indicates non-AST
mode. For more information about failover, see the topic Limited
access during failover.
Indicates that the call is using a wideband codec for good quality
voice call.
Indicates a low network performance or presence of local
network issues that might result in lower call quality.
Indicates that the user enabled the LNCC feature. The LNCC
feature changes the Multiple Call Appearance deskphone to a
Single Call Appearance deskphone.
Indicates the extend call feature. The extend call feature allows
you to transfer a deskphone call to your mobile phone.
Indicates that the end to end call is secured.
Indicates that the SLA Mon
™
agent has taken control of the
deskphone.
Indicates that the call is being recorded for SLA Mon
™
.
Indicates the Team button ringing state.
Indicates that the Send All Calls feature is on.
Presence icons appear when you set up the person whose presence you want to track as a
contact and enter a handle (a phone number or URI) for that person.
Call history icons for 9608/9608G deskphones
The following icons indicate the types of calls.
Icon
Name Description
Missed call Indicates that you did not answer
the call or had forwarded the call
to your voice mail.
Answered call Indicates that you have answered
the call.
Table continues…
Call history icons for 9608/9608G deskphones
October 2019 Using Avaya 9601 IP Deskphone SIP 21
