Converting PNs to IP-PNC
1044 Upgrading, Migrating, and Converting Media Servers and Gateways
Note:
Note: The TN2602 Media Resource 320 circuit pack is unavailable for installation in the
CMC1 or the G600 media gateways.
Reliability levels
Avaya communications systems that are controlled by the S8500 media server have no
duplication. This configuration is sometimes referred to as simplex reliability. Communications
systems that are controlled by S8700-series media servers can have one or a combination of
the following three duplication or reliability levels:
● Duplex
S8700-series media servers that are duplicated, which is the standard configuration
● High
Duplicated media servers and control network.
● Critical
Duplicated media servers, control network, and bearer network.
S8700/
S8710/
S8720
CMC1 Yes No No Single control network and
single bearer network
G600 Yes No No Same as CMC1 with
S8700-series
G650 Yes Yes Yes —
requires
an MCC1
for CSS
- Single control and bearer
- duplicated control
- duplicated control and
bearer
SCC1 Yes Yes Yes —
requires
an MCC1
for CSS
Same as G650 with
S8700-series
MCC1 Yes Yes Yes Same as G650 with
S8700-series
Table 21: Gateways supported in IP-PNC and fiber-PNC configurations (continued)
Server Supported
Central
Gateways
IP-PNC Direct-
connect
CSS/ATM-
connect
Reliabilities supported
2 of 2
