102 User’s Manual—SNAP™ 700 Printer
Classification: Avery Dennison - Public
Interface
Null modem serial cable DB9 F connector
May require USB/serial adapter
May require external Ethernet adapter
Control Panel
Push-button start/stop with 4 LED lights – Ready, Data, Supply, Error voice button
Dimensions
18.5" (470mm) high x 25" (635mm) wide
Including stacker x 20.0" (508.0mm) deep
Weight
80 Lbs. (36.3 Kg.)
Electrical
90-132 / 180-265 VAC 50-60Hz - 10 / 6 Amp 1 Ph User selectable
Temperature
40F (4C) to 95F (35C)
Humidity
5% to 90% non-condensing
Other
Features
- Downloading of information while machine is operating
- Sequenced Fields
- Time/Date Stamping (Both month/day/year and day/month/year format)
- Life Counts – through PCMate Platinum
- Operator adjustable: Contrast – Adjustable on printhead
- Cut position, print position and baud rate – Adjustable through PCMate Platinum virtual display
- Error Detection of: Stock out, ink out, print head open, feed open, full stacker, stacker jam, and
print head over-temperature – with voice commands.
- Display: Labels left to be cut and stacked in a batch, batch ID, total life inches, total life cuts
- Self Diagnostics – through PCMate Platinum
- Missed sense mark detection and correction
- Reflective sensor — reads black sense mark printed on front or back of white preprinted stock,
full adjustment across the web.
Ink Ribbon
AVERY DENNISON standard thermal colors and widths
AVERY DENNISON white plastic core: Maximum Ink O.D. 3.5”
Ink widths:
With Metric Adapter - 25mm to 127mm metric widths in 5mm increments.
With Inch Adapter - 1” to 5” inch widths in ¼” increments.
Options
- Short Feed Accessory – reduces the minimum cut label to .75” (19mm) tested to stack as short
as 1” feed. Supply dependent based on static properties of the material and environment
conditions that may limit the stack height to 1” (25mm).
- Contrast or color sensor — Reads sense mark printed on front of preprinted stock. Sense mark
or stock may be colored.
- Bar code verifier — Scans every bar code printed. Stops printer if a bar code does not scan.
- RFID Accessory – Printer can encode stocks that are made with known RFID components. Print
speed is 2 or 3 ips to program the RFID component on the fly.
Default Serial
Port Setup
The default serial port configuration is 115,200 baud, no parity, 8 data bits, 1 stop bit.
