Avery Dennison SNAP 700 - Knife Assembly Parts List

User’s Manual—SNAP™ 700 Printer 151
Classification: Avery Dennison - Public
Knife Assembly Parts List
ITEM
PART NO.
DESCRIPTION
QTY
1
05627307
BRKT, SHORT FEED MOUNT, REAR
1
2
05999001
R6FF BEARING
2
3
05999097
BUSHING, FL 1/4 X 3/8 X 3/16
1
4
05627009
BASE, KNIFE SUPPORT
1
5
05627091
ASSEMBLY, GROUND ROTARY
1
6
05627308
BRKT, SHORT FEED MOUNT, FRONT
1
7
05357093
ASSEMBLY, STATIONARY KNIFE
1
8
05627014
BRIDGE BLADE, KNIFE OUTPUT
1
9
05990066
8:32X1/4 BTN. SCREW
4
10
05627013
BRIDGE BLADE, KNIFE
1
11
05990019
6:32X1/4 B.H. SCREW
2
12
05517021
BLOCK, SHEAR ADJUST
1
13
05990015
6-32 X 1/4 CAP SCREW
1
14
05627024
BRACKET, BRIDGE BLADE
2
15
05991253
SCREW, 6-32 BUTTON HEAD CS X 3/16
4
16
05357095
ASSEMBLY, OILER MOUNT
1
17
05990055
8:32X3/8 F. H. SCREW
6
18
05197319
TORSION SPRING,RIGHT
1
19
05357029
TORSION SPRING BACK, DC KNIFE
1
20
05990025
6:32 X 1/4 SET SCREW
2
21
05990120
1/4:20 X 1/2 CAP SCREW
2
