15.1.3 Short Feed Assembly Part List
ITEM
PART NO.
DESCRIPTION
QTY
1
05197319
TORSION SPR FRONTDC KNIFE
1
2
05357029
TORSION SPR BACK, DC KNIFE
1
3
05357093
ASSEMBLY, STATIONARY KNIFE
1
4
05448010
STATIC BRUSH
1
5
05517021
BLOCK, SHEAR ADJUST
1
6
05627024
BRACKET, BRIDGED BLADE
2
7
05627091
ASSEMBLY, GROUND ROTARY
1
8
05627301
SHAFT, SHORT FEED NIP EXT
1
9
05627302
FLEX BEAM COUPLING
1
10
05627303
BRKT, SHORT FEED NIP STRIPPER
1
11
05627304
O-RING, SHORT FEED
4
12
05627305
BRKT, SHORT FEED FRONT
1
13
05627306
BRKT, SHORT FEED REAR
1
14
05627307
BRKT, SHORT FEED MOUNT, REAR
1
15
05627308
BRKT, SHORT FEED MOUNT, FRONT
1
16
05627309
SHAFT, SHORT FEED INNER IDLER
1
17
05627310
SHAFT, SHORT FEED OUTER IDLER
1
18
05627311
SHAFT, SHORT FEED INNER DRIVE
1
19
05627312
SHAFT, SHORT FEED OUTER DRIVE
1
20
05627313
BRKT, SHORT FEED STACKER MOUNT
1
21
05627318
ASSY, KNIFE GUARD
1
22
05627319
BASE, SHORT FEED KNIFE SUPPORT
1
23
05990015
6-32 X 1/4 SHCS
1
24
05990025
6-32 X 1/4 SET SCREW
2
25
05990055
8-32 X 3/8 FHCS
6
26
05990057
8-32 X 1/8 KNURLED CUP POINT
4
27
05990066
8-32 X 1/4 BHCS
2
28
05991253
6-32 X 3/16 BHCS
4
29
05991454
8-32 X 1/4" THUMB SCREW
2
30
05991523
SPRING, COMP 500/600 NIP ASSEMBLY
4
31
05991651
6-32 X 7/8 BHCS
2
32
05999001
R6FF BEARING
2
33
05999097
BUSHING, FL 1/4 X 3/8 X 3/16
1
