20 User’s Manual—SNAP™ 700 Printer
Classification: Avery Dennison - Public
They have knobs for adjusting print head pressure and print density to
control the print quality.
The Upper and Lower Ink Arbors are adjusted using the black knob on
the end of the arbor. To open up and close down the self-center arbor to
the ink cores rotate the knob. Do not over tighten onto the core to hole
them in place. They accommodate ink rolls ranging from 1 inch (25mm)
to 5 inches (127 mm) cores.
A Rotary Knife Assembly comes with printer. When printing woven
tapes, use a Sonic Knife accessory option that provides ultrasonic cutting
and sealing.
The Stacker collects the finished, printed labels. You can adjust it to
accommodate a variety of label stocks and short or long labels. Once the
stacker reaches the bottom, the printer will stop, indicate the stacker is
full, and allow you to remove the labels.
The Control Panel with buttons and LED’s indicate printer status and
information about specific jobs.
WARNING: This is a class A product. In a domestic environment
this product may cause radio interference in which case the user
may be required to take adequate measures.
3.4.2 Printer Configurations
The Snap 700 comes in 2 configurations:
1 over 1 – The Snap 700 1 over 1 features one upper print head over
one lower print head, capable of printing a two sided label.
1 over 0 – The Snap 700 1 over 0 features one print head on top only.
