User’s Manual—SNAP™ 700 Printer 41
Classification: Avery Dennison - Public
Use the Start / Stop and Voice buttons to move through the Option Menu
System. Each time you press a key, a voice message will follow, or the machine
will initiate or stop an action. Regardless of which of the three functions you want
to select in the Option Menu System, you select it the same way:
1. Press and hold the Voice button for about two seconds.
2. The Voice message will say, “Press Start for Test Pattern.”
3. If you do not want to run a test pattern, press the Voice button.
4. The voice message will say, “Press Start for Demos.”
5. If you do not want to listen to the demos, press the Voice button.
6. The voice message will respond with, “Press Start to Set Volume.”
7. If you do not want to change the speaker volume, press the Voice button.
8. The printer will say “Returning to Print Mode.” At this time the Option
Menu System is complete and the printer is back to normal operation.
For more information on how to use each of the three possibilities in the Option
Menu System, Running Test Labels; Using Voice Demos; and Setting / Adjusting
Voice Button Volume. Appendix 8 contains a flowchart of the Option Menu
System.
4.5.1 Running Test Patterns
Your SNAP 700 printer offers you two Test Patterns to run before you proceed to
production.
Test Pattern 1 (Narrow Setup Test Pattern), is a format designed to run on a 2”
wide fabric. It consists of a solid line down the middle on the front and back of
the label and a solid line across the web that is exactly 1” from the cut, along with
a 2” wide brick pattern. These lines are helpful in adjusting print position to
compensate for mechanical tolerances in the printer, and the brick pattern can be
used to detect dot out in the head.
Test Pattern 2 (Wide Setup Test Pattern) is similar to Test Pattern 1, except
that it is designed to run on a 5” wide stock.
Test Pattern 3 and 4 (Custom Test Pattern 1 and Custom Test Pattern 2)
more closely resemble actual labels and can be used to make adjustments to the
printhead pressure and contrast (see section 4.1.1 and 4.1.2).
When you have determined which Test Pattern you wish to operate, use the
appropriate procedure.
NOTE: The printer is set up to print the selected label test
format in a very large quantity. You must manually start
and stop the printing to make any necessary adjustments
and to end the test run.
