Avery Dennison SNAP 700 - Stacker Mechanical Problems

User’s Manual—SNAP™ 700 Printer 97
Classification: Avery Dennison - Public
10.5 Stacker
Problem
Probable Cause
Corrective Action
Stacker fails to move up
or down when start
button is depressed.
1) Interface cable
1) Not plugged in all the way.
2) Just installed and needs to be power cycled
for printer to identify option installed.
3) Printer has no batches to print.
Platform can not find
home
1) Sensor unplugged
1) Remove back cover and check
connections.
2) Broken wire or damaged LED
2) Sensor out of alignment
1) Outer bracket bent and needs to be
reformed.
Top of stack is blocking
incoming labels
2) Sensor not operational
1) Check sensor alignment
2) Stacker not connected
3) Loose connection
Stack of labels falling
over
2) Static brush position
1) Move static brush up or down
3) Platform angle
1) Move to other position
4) Tip stacker
1) Change angle
Label not entering
stacker
1) Label jam in knife
1) Clean out label and debris
2) Nip roller not pulling
1) Worn rubber roller - Replace
2) Loose set screw or drive gear - Tighten
3) Soft material / narrow web
hitting static brush
1) Adjust the height of the static brush
IF THE RECOMMENDED CORRECTIVE ACTIONS DO NOT
RESOLVE THE PROBLEM(S), CONTACT YOUR LOCAL
AVERY DENNISON REPRESENTATIVE.

