Avery Dennison SNAP 700 - Page 125

User’s Manual—SNAP™ 700 Printer 125
Classification: Avery Dennison - Public
Unwind Assembly RFID 3” / 4” Parts List
ITEM
PART NO.
DESCRIPTION
QTY
1
05623020
SHAFT, QUICK ATTACH UNWIND THREADED
1
2
05724022-1
AXLE SUPPORT
1
3
05623004
SHAFT, CORE LOCATOR
3
4
05990325
SNAP RING, 3/16 "E" RING
6
5
05593002
HUB, OUTER, UNWIND
1
6
05583009
DRAG PLUG, UNWIND
1
7
05991443
SPRING, COMPRESSION
1
8
05989971
5/16:18 X 3/8 LG SET SCREW W/HALF DOG TIP
1
9
05623008-1
BRACKET, CORE LOCATOR
3
10
05990037
WASHER, #6 SAE
3
11
05990018
6:32 X 3/4 CAP SCREW
3
12
05989987
6-32 E-S NUT
3
13
05623012
SUPPORT, OUTER UNWIND
1
14
05583006
KNOB, UNWIND
1
15
05990052
8:32 X 1/2 CAP SCREW
2
16
05623001
HUB, INNER UNWIND, 3"
1
17
05623009
ADAPTER, 4" HUB
1
18
05623010
RING, UNWIND HUB
1
19
05990028
6:32X3/8 SOCKET F.HD. SCREW
3
20
05623011
SPRING CLAMP
1
21
05990019
6:32X1/4 B.H. SCREW
1
22
05634051
SHAFT, QUICK ATTACH UNWIND
1
23
05996311
4 SCREW, 4-40 X 5/8 PPHS W/ EXT TOOTH LOCK WASHER
1
