Web Guide Assembly Parts List
ITEM
PART NO.
DESCRIPTION
QTY
1
05624057
SHAFT, INK TURN
1
2
05991374
1/4-20 X 1/2 PAN PHILLIPS
1
3
05624089
ASSY, WEB GUIDE MOUNT
2
4
05624050
SHAFT, WEB ADJUST
1
5
05990325
SNAP RING, 3/16 "E" RING
1
6
05196028
KNOB, BLACK (GLOSS) .187 SHAFT HOLE BUSHING SOCKET SET SCREW
1
7
05624049
WEB GUIDE, REAR
1
8
05624047
WEB GUIDE, FRONT
1
9
05990484
1/4:20X1/2 NYLON SLOTTED SCREW
1
