Sensor Tray Assembly Parts List
ITEM
PART NO.
DESCRIPTION
QTY
ITEM
PART NO.
DESCRIPTION
QTY
1
05624042
SUPPORT, WEB GUIDE, REAR
1
21
05989994
2-56 X 1/2 HEX SOCKET HD CAP SCREW
2
2
05999100
BUSHING, FL 3/16 X 5/16 X 1/8
4
22
05624045
BRIDGE BLADE, TOP
1
3
05624009
SHAFT, WEB TURN, STACKER MOUNT
1
23
05624033
SHAFT, SENSOR ADJUST, LOWER
1
4
05624041
SUPPORT, WEB GUIDE
1
24
05624031
BLOCK, SENSOR MOUNT
1
5
05624043
SUPPORT, WEB GUIDE, FRONT
1
25
05554005
DRIVE, WEB GUIDE ADAPTER
1
6
05990051
8:32 X 3/8 CAP SCREW
4
26
05626016
SHAFT, ECCENTRIC TURN BAR
1
7
05624034
PIN, IDLER GEAR
1
27
05626017
TUBE, ECCENTRIC TURN BAR
1
8
05990028
6:32X3/8 SOCKET F.HD. SCREW
1
28
05626019
INSERT, ECCENTRIC FOIL SHAFT
1
9
05990120
1/4:20 X 1/2 CAP SCREW
3
29
113742
SUPPORT-ADJ ROLLER-M01460-TOOL T-
10222
1
10
05990133
1/4:20 X 3/4 F H SCREW
2
30
113744
ECCENTRIC-ADJ #2 M01460-TOOL 10222
1
11
05444018U
DRIVE, SPUR 20T GEAR
1
31
05990017
6:32 X 1/2 CAP SCREW
1
12
05624032
SHAFT, SENSOR ADJUST, UPPER
1
32
05990312
KNOB, SZ 6 THUMB SCREW
1
13
05354009
GEAR, DRIVEN
2
33
999083012
M3 X 6mm PHIL PAN HEAD SCREW
1
14
05196028
KNOB, BLACK (GLOSS) .187 SHAFT
HOLE
BUSHING SOCKET SET SCREW
1
15
05624044
BRIDGE BLADE, BOTTOM
1
16
05990055
8:32X3/8 F. H. SCREW
2
17
05990066
8:32X1/4 BTN. SCREW
6
18
05624030
BLOCK, LED MOUNT
1
19
05581128
SENSOR, REFLECTIVE HARNESSED
2
20
05989985
WASHER, #2 SAE
2
