Sensor Tray RFID Assembly Parts List
ITEM
PART NO.
DESCRIPTION
QTY
ITEM
PART NO.
DESCRIPTION
QTY
1
5624042
SUPPORT, WEB GUIDE, REAR
1
22
5624030
BLOCK, LED MOUNT
1
2
5624041
SUPPORT, WEB GUIDE
1
23
5624031
BLOCK, SENSOR MOUNT
1
3
5624043
SUPPORT, WEB GUIDE, FRONT
1
24
5554005
DRIVE, WEB GUIDE ADAPTER
1
4
5999100
BUSHING, FL 3/16 X 5/16 X 1/8
4
25
5990017
6:32 X 1/2 CAP SCREW
1
5
5354009
GEAR, DRIVEN
2
26
5990312
KNOB, SZ 6 THUMB SCREW
1
6
5624033
SHAFT, SENSOR ADJUST, LOWER
1
27
5581128
SENSOR, REFLECTIVE HARNESSED
2
7
5624032
SHAFT, SENSOR ADJUST, UPPER
1
28
5989985
WASHER, #2 SAE
2
8
5624034
PIN, IDLER GEAR
1
29
5989994
2-56 X 1/2 HEX SOCKET HD CAP SCREW
2
9
05444018U
DRIVE, SPUR 20T GEAR
1
30
5626016
SHAFT, ECCENTRIC TURN BAR
1
10
5990028
6:32X3/8 SOCKET F.HD. SCREW
1
31
5626017
TUBE, ECCENTRIC TURN BAR
1
11
5990120
1/4:20 X 1/2 CAP SCREW
3
32
5626019
INSERT, ECCENTRIC FOIL SHAFT
1
12
5990051
8:32 X 3/8 CAP SCREW
4
33
113742
SUPPORT-ADJ ROLLER-M01460-TOOL T-
10222
1
13
5196028
KNOB, BLACK (GLOSS) .187 SHAFT
HOLE BUSHING SOCKET SET SCREW
1
34
113744
ECCENTRIC-ADJ #2 M01460-TOOL 10222
1
14
5624058
BRIDGE BLADE, BOTTOM
1
35
5989530
3MM X 6MM PAN HD PHIL HD SC
3
15
5624059
BRIDGE BLADE, TOP
1
36
05624109-1
BRACKET, RFID ANTENNA (ADJ F. TO B.)
1
16
5990055
8:32X3/8 F. H. SCREW
2
37
5990050
8:32 X 1/4 CAP SCREW
2
17
5990066
8:32X1/4 BTN. SCREW
6
38
5624069
GUARD, RFID ANTENNA
1
18
5624009
SHAFT, WEB TURN, STACKER MOUNT
1
39
126547
PWA, RFID ANTENNA 902-928 MHZ
(REPLACES 126354)
1
19
5990133
1/4:20 X 3/4 F H SCREW
2
40
5624064
SPACER, RFID ANTENNA
2
20
5990374
COLLAR, 1/2"
2
41
5991074
3 X 12MM FLAT HEAD SCREW
2
21
5990484
1/4:20X1/2 NYLON SLOTTED SCREW
2
42
125731
BOX, ANTENNA
1
